CPTAU Pre-insulated Bimetal Lug

●The CPTA4 pre-insulated bimetal lug is used to establish connection between LV-ABC cable and electrical equipments.

●Palm is made of 99.9% pure copper and sleeve is made of 99.6% pure aluminium.

●Cross-section of conductor can be easily identified by the color code of elastomeric rings.

●Elastomeric ring and pre-filled grease enable super waterproof performance.

●Watertightness test carried out at 6kV for i minute under water.

●Insulation tube is made of weather and UV resistant polymer.

●Standard:EN 50483-4 .NFC 33-021.
